2 усилитель канала 26В 700кХз ЛМ2904ДРГ4 рабочий

2 усилитель канала 26В 700кХз ЛМ2904ДРГ4 рабочий

MOQ: 10пкс
цена: Подлежит обсуждению
standard packaging: 2500ПКС/РЭЭЛ
Delivery period: 2-3дайс
payment method: Т/Т, западное соединение
Supply Capacity: 25000ПКС/ВЭЭК
Подробная информация
Место происхождения
МАЛ АИСИА
Фирменное наименование
TI
Сертификация
ROHS
Номер модели
ЛМ2904ДРГ4
Тип продукта:
Рабочий Усилител-Оп Амп
Стиль установки:
СМД/СМТ
Пакет/коробка:
СОИК-8
Количество каналов:
Канал 2
Поставка напряжени тока-Макс:
26 в
продукт ширины полосы частот ГБП-увеличения:
700 КГц
Течение выхода в канал:
30 мам
Тариф Старший-преобразования:
0,3 В/ус
Напряжение смещения Вос-входного сигнала:
7 мВ
Напряжени тока-минимум поставки:
3 в
Ток смещения Иб-входного сигнала:
нА 250
Работая течение электропитания:
350 уА
Конец:
Отсутствие выключения
КМРР-общий коэффициент сброса режима:
дБ 65 к дБ 80
плотность шума напряжения тока ен-входного сигнала:
40 нВ/скрт Хз
Пакет:
вьюрок
Тип усилителя:
Высокий маломощный усилитель напряжения
Особенности:
Оптимизированная цена
Тип входного сигнала:
Рельс, который нужно проложить рельсы
Тип электропитания:
Одиночный, двойной
Технология:
Двухполярный
Двойная подача напряжения:
+/- 3 В, +/- 5 В, +/- 9 В, +/- 12 В
Максимальная двойная подача напряжения:
+/- 13 в
Минимальная двойная подача напряжения:
+/- 1,5 в
Работая напряжение тока электропитания:
3 в к 26 в, +/- 1,5 в до +/- 13 в
Субкатегоры:
Усилитель ИКс
Вкм-общее напряжение тока режима:
Отрицательный рельс к положительному Райл-1.5 в
ДБ увеличения напряжения тока:
дБ 100
Выделить:

микро- интегральная схемаа

,

компоненты интегральной схемаы

Product Description

Texas Instruments LM2904DRG4 Operational Amplifier Op Amp Dual General Purpose Op Amp



Operational Amplifier

Controlled Baseline One Assembly/Test Site, One FabricationSite Extended Temperature Performance of
−40°C to 125°C
 Enhanced Diminishing Manufacturing
Sources (DMS) Support
 Enhanced Product-Change Notification
 Qualification Pedigree† ESD Protection Exceeds 500 V Per
MIL-STD-883, Method 3015; Exceeds 200 V
Using Machine Model (C = 200 pF, R = 0)
 Low Supply-Current Drain Independent of
Supply Voltage . . . 0.7 mA Typ
† Component qualification in accordance with JEDEC and industry
standards to ensure reliable operation over an extended
temperature range. This includes, but is not limited to, Highly
Accelerated Stress Test (HAST) or biased 85/85, temperature
cycle, autoclave or unbiased HAST, electromigration, bond
intermetallic life, and mold compound life. Such qualification
testing should not be viewed as justifying use of this component
beyond specified performance and environmental limits.
 Common-Mode Input Voltage Range
Includes Ground, Allowing Direct Sensing
Near Ground
 Differential Input Voltage Range Equal to
Maximum-Rated Supply Voltage:
− Non-V Devices . . . ±26 V
− V-Suffix Devices... ±32 V
 Low Input Bias and Offset Parameters:
− Input Offset Voltage . . . 3 mV Typ
− Input Offset Current . . . 2 nA Typ
− Input Bias Current . . . 20 nA Typ
 Open-Loop Differential Voltage
Amplification . . . 100 V/mV Typ
 Internal Frequency Compensation

 2 усилитель канала 26В 700кХз ЛМ2904ДРГ4 рабочий 0

                                                   description/ordering information
This device consists of two independent, high-gain, frequency-compensated operational amplifiers designed
to operate from a single supply over a wide range of voltages. Operation from split supplies is possible as long
as the difference between the two supplies is 3 V to 26 V (3 V to 32 V for V-suffix devices), and VCC is at least
1.5 V more positive than the input common-mode voltage. The low supply-current drain is independent of the
magnitude of the supply voltage.
Applications include transducer amplifiers, dc amplification blocks, and all the conventional operational
amplifier circuits that now can be implemented more easily in single-supply-voltage systems. For example,
these devices can be operated directly from the standard 5-V supply used in digital systems and easily provide
the required interface electronics without additional ±5-V supplies.

2 усилитель канала 26В 700кХз ЛМ2904ДРГ4 рабочий 1

Q1. What is your terms of packing?

A: Generally, we pack our goods in neutral white boxes and brown cartons.

If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.



Q2. What is your MOQ?

A: We provide you small MOQ for each item, it depends your specific order!



Q3. Do you test or check all your goods before delivery?

A: Yes, we have 100% test and check all goods before delivery.



Q4: How do you make our business long-term and good relationship?

We keep good quality and competitive price to ensure our customers benefit ;

We respect every customer as our friend and we sincerely do business and make friends with them,It's not something that can be replaced.



Q5: How to contact us?
A: Send your inquiry details in the below,Click "Send"Now!!!



Shenzhen Hongxinwei Technology Co., Ltd

To adopt new technology,to produce products of quality,to offer high-class service.

Improve the management system continuously to meet customer requirement for high-quality products and services.



Why choose us?

  • 100% new and originao with Advantage price
  • High efficiency
  • Fast Delivery
  • Professional team service
  • 10 Years Experience Electronic components
  • Electronic components Agent
  • Advantage logistic discount
  • Excellent After-sales Service
